WiFi 5 CATV ONU Optical for FTTx GPON ONU

Integration of Television and Network

Technical Parameter

WiFi 5 CATV ONU Optical Network Terminal for FTTx GPON Solutions

This advanced GPON ONU integrates high-speed optical access, WiFi 5 wireless connectivity, and CATV broadcast signal distribution, designed for Fiber-to-the-x (FTTx) deployments. It delivers triple-play services (voice, video, data) over a single fiber infrastructure, supporting future-proof network scalability and superior user experiences.

Key Features:

1. GPON Compliance: Adheres to ITU-T G.984 standards for seamless integration into existing GPON networks.

2. Dual-Band WiFi 5: 2.4GHz + 5GHz concurrent radios with MU-MIMO, enabling 1.2Gbps aggregate throughput and stable multi-device connectivity.

3. CATV Support: Integrates RF overlay for cable TV signal transmission over coaxial cables, supporting up to 1GHz bandwidth.

4. Triple-Play Services: Unified platform for broadband internet, VoIP telephony, and digital TV broadcasting.

5. QoS Management: Granular traffic prioritization for latency-sensitive applications (e.g., VoIP, IPTV).

6. Remote Management: TR-069 protocol support for automated configuration, firmware updates, and fault monitoring.

7. Security: WPA3 encryption, MAC filtering, and VLAN isolation to safeguard network integrity.

8. Scalability: Supports up to 32 Wi-Fi clients simultaneously, ideal for MDUs, offices, or hospitality venues.

5-Question FAQ:

1. Q: What advantages does WiFi 5 offer over older standards in this ONU?
   A: WiFi 5 (802.11ac) provides dual-band concurrency, MU-MIMO spatial streaming, and 1.2Gbps throughput, reducing interference and improving multi-device performance compared to WiFi 4.

2. Q: How does the CATV integration work with existing coaxial wiring?
   A: The ONU includes an RF overlay module that modulates digital TV signals onto coaxial cables, allowing reuse of existing in-home TV cabling for IPTV/CATV distribution.

3. Q: Can this device support 4K streaming and VoIP simultaneously without lag?
   A: Yes. The QoS engine prioritizes real-time traffic (VoIP, video) while allocating sufficient bandwidth for 4K streams, even during peak usage.

4. Q: What installation scenarios is this ONU optimized for?
   A: It suits FTTB/FTTH deployments in apartments, hotels, or small businesses requiring high-speed internet, voice, and TV over a single fiber drop.

5. Q: Is remote management secure? What protocols are used?
   A: Remote management uses TR-069 over HTTPS with AES encryption. Credentials are stored in a hardware-secured vault, and updates are signed to prevent tampering.
